Bangles & Rings Faceting Machines

FX-1TMC Diamond Faceting Bangle & Rings

The FX-1TMC is a CNC-controlled 5-axis turning, milling, and centering machine engineered for advanced 2D and 3D machining operations. Designed for professional jewellery and precision metal applications, it delivers exceptional accuracy, stability, and mirror-like finishes across intricate multi-surface components.

  • Vertical high-speed spindle (40,000 RPM) for complex turning and milling tasks with flawless surface quality.
  • 20-tool Automatic Tool Changer (ATC) and advanced 5-axis designing software for efficient production and reduced setup time.
  • Compact footprint (55 × 57 × 68 in) powered by 3-phase 440 V, 7.5 kW installed power, and 6-bar air support for speed, power, and reliability.
Download Brochure Request A Quote

FX-1TMC: FX Series: Turning, Milling & Centering

Specification

The FX-1TMC is a high-precision 5-axis CNC turning, milling, and centering machine designed for advanced 2D and 3D machining operations across a wide range of jewellery and precision metal components. Equipped with a vertical high-speed spindle operating at 40,000 RPM, it delivers exceptional accuracy, surface finish, and stability for complex turning and milling tasks.

Featuring 7 control axes (X, Y, Z, B, C, W, SP) with 5-axis simultaneous operation, the FX-1TMC offers complete flexibility in machining intricate designs and multi-surface components with mirror-like precision. Its 20-tool Automatic Tool Changer (ATC) and advanced 5-axis designing software enable smooth transitions, reduced setup time, and efficient production of both detailed artistic patterns and technical forms.

Powered by a 3-phase 440V system with 7.5 kW installed power and supported by a 6-bar air supply, the FX-1TMC combines speed, power, and reliability within a compact footprint of 55 x 57 x 68 inches. Ideal for professional jewellery manufacturers and precision engineers, this machine delivers unrivaled performance, accuracy, and finishing quality for high-end turning and milling applications.

MACHINE NAMEFX – 1TMC
CONTROLLERCNC
MAX CONTROL AXIS7
SIM CONTROL AXIS5
AXISX/Y/Z/B/C/W/SP
SPINDLEVERTICAL
SPINDLE SPEED – RPM40000RPM
HEADSVERTICAL
ATC20
DESIGNING SOFTWARE5 AXIS DESIGNING SOFTWARE
AIR SUPPLY6 BAR
POWER SUPPLY3 PHASE – 440V
INSTALLED POWER7.5KW
FUNCTIONWITH ONLY VERTICAL HEAD, 2D & 3D – DEPENDS ON DESIGN POSSIBILITIES – PURE 5 AXIS WITH TURNING
L X B X H55x57x68 INCH
WEIGHT1250KG

FX-1TMC: FX Series: Turning, Milling & Centering

FX-1TMC: FX Series: Turning, Milling & Centering

FX-1TMC: FX Series: Turning, Milling & Centering

FX-1TMC: FX Series: Turning, Milling & Centering
